Rockville RPA14 7000 Watt Peak / 2000w RMS 2 Channel Power Amplifier Pro/DJ Amp
Price: $324.95
(as of May 14,2023 00:51:40 UTC – Details)
From the manufacturer
Rockville RPA14 7000 Watt Peak / 2000w RMS 2 Channel Power Amplifier Pro/DJ Amp
Power Ratings:
RMS Power Output:Stereo 8 Ohm: 2 x 700WStereo 4 Ohm: 2 x 1000WBridged 8 Ohm: 1 x 2000WPeak Power Output:Stereo 4 Ohm: 2 x 3500W MaxBridged 8 Ohm: 1 x 7000W Max
Terminals:
Input Terminals:Combo jack (XLR and ¼”) A & B inputsOutput Terminals:Banana binding post speaker outputSpeakon outputXLR output to connect another amplifier or powered sub
Features:
Rockville RPA14 7000 Watt Peak 2 Channel Professional/DJ Rack Mount AmplifierLCD displays volume in dB per channel and operating temperature2U rack spaceBuilt in limiter protects your speakers from distortion and clippingBridged mode allows you to combine both channels power into one channel for use with a subwooferStereo mode is perfect for (2) speakers or (4) speakers in a left and right configurationParallel mode gives you dual mono output signal which is perfect for monitor use when you want all sounds coming out of each speaker instead of a left/right configurationBuilt in crossover switch (bypass, 80 Hz, 160 Hz) allows amp to be used with full range PA speakers, or Subwoofer(s)Channel A & B Clipping Led IndicatorsChannel A & B Separate Level ControlsPower, signal, clipping, and protection LED indicators on front of ampHeavy duty rack mount earsBuilt-in variable high velocity quiet cooling fansMaximum headroom for 4-ohm and 8-ohm Speakers
Level controls for precise setting and matching of sensitivityComputer controlled IC protection circuitry against speaker short circuit, thermal over load, DC over loadUser serviceable fuse (20A, 250V)Frequency Response (bandwidth @ 2Vrms out, @ -3.0dB) 10 Hz – 30 KhzTHD + Noise @ 1Khz full power: <0.03%Input Impedance: 10K Ohm BalancedInput signal voltage: 660mV – 1.5VInput sensitivity: 0.7vDamping factor: ( 100Hz, 10w, 4 ohms): 43.4Damping factor: (1Khz @ 8 ohm): >400:1Effective damping factor (100Hz, 10w, 4 Ohms) 1.08Output impedance at speaker terminals: 0.09214 OhmsFrequency Response vs THD+N (worst case, across normal bandwidth 1W) 0.6%Signal to Noise Ratio: > 100dBIMD 60Hz & 1kHz, 4:1: <0.04%SLEW RATE (input filter limited) : 40v/uSPower Requirements: 120V / 50-60HzWeight: 28.7 lbsDimensions: 19.09 x 16.93 x 3.35 inch
Rockville RPA14 7000 Watt Peak 2 Channel Professional/DJ Rack Mount Amplifier. LCD displays volume in dB per channel and operating temperature. 2U rack space. Built in limiter protects your speakers from distortion and clipping. Bridged mode allows you to combine both channels power into one channel for use with a subwoofer. Stereo mode is perfect for (2) speakers or (4) speakers in a left and right configuration. Parallel mode gives you dual mono output signal which is perfect for monitor use when you want all sounds coming out of each speaker instead of a left/right configuration
Built in crossover switch (bypass, 80 Hz, 160 Hz) allows amp to be used with full range PA speakers, or Subwoofer(s). Channel A & B Clipping Led Indicators. Channel A & B Separate Level Controls. Power, signal, clipping, and protection LED indicators on front of amp. Heavy duty rack mount ears. Built-in variable high velocity quiet cooling fans. Maximum headroom for 4-ohm and 8-ohm Speakers. Level controls for precise setting and matching of sensitivity
Computer controlled IC protection circuitry against speaker short circuit, thermal over load, DC over load. User serviceable fuse (20A, 250V). Frequency Response (bandwidth @ 2Vrms out, @ -3.0dB) 10 Hz – 30 Khz. THD + Noise @ 1Khz full power: <0.03%. Input Impedance: 10K Ohm Balanced. Input signal voltage: 660mV – 1.5V. Input sensitivity: 0.7v. Damping factor: ( 100Hz, 10w, 4 ohms): 43.4. Damping factor: (1Khz @ 8 ohm): >400:1
Effective damping factor (100Hz, 10w, 4 Ohms) 1.08. Output impedance at speaker terminals: 0.09214 Ohms. Frequency Response vs THD+N (worst case, across normal bandwidth 1W) 0.6%. Signal to Noise Ratio: > 100dB. IMD 60Hz & 1kHz, 4:1: <0.04%. SLEW RATE (input filter limited) : 40v/uS. Power Requirements: 120V / 50-60Hz. Weight: 28.7 lbs. Dimensions: 19.09 x 16.93 x 3.35 inch
